| Allmänt |
| Typ av enhet | Värdbussadapter |
| Formfaktor | Instickskort - låg profil |
| Gränssnittstyp (buss) | PCI Express x8 |
| Version av PCI-specifikation | PCIe 2.0 |
| Nätverk |
| Portar | 8Gb Fibre Channel x 2 |
| Anslutningsteknik | Kabelansluten |
| Datalänkprotokoll | 8 Gb fiberkanal (Short Wave) |
| Dataöverföringshastighet | 8.5 Gbps |
| Funktioner | Auto-negotiation |
| Expansion/Anslutning |
| Expansionskortplatser | 2 (totalt)/ 0 (ledig) x SFP+ |
| Gränssnitt | 2 x 8 GB fiberkanal (kortvåg) - LC multiläge - x 2 |
| Kompatibla kortplatser | 1 x PCI Express x8 |
| Diverse |
| Inkluderade tillbehör | Hållare för låg version |
| Typ av prissättning | Begagnat |
| Programvara / Systemkrav |
| Operativsystem erfordras | Microsoft Windows Server 2003, SunSoft Solaris 10, Red Hat Enterprise Linux 4 for x86/ AMD64/ EM64T, SuSE Linux Enterprise Server 11 for x86/AMD64/Intel EM64T, SuSE Linux Enterprise Server 10 for x86/AMD64/Intel EM64T, Red Hat Enterprise Linux 5 for Intel x86 / AMD64 / EM64T, Microsoft Windows Server 2008, VMware ESX Server 3.5 |
| Dimensioner och vikt |
| Djup | 16.8 cm |
| Höjd | 6.4 cm |
| Miljöparametrar |
| Min temperatur vid drift | 0 °C |
| Max temperatur vid drift | 55 °C |
| Luftfuktighet vid drift | 10 - 90% |
| Kompatibilitetsinformation |
| Designat för | HPE ProLiant DL160 G5 Special Server, DL160 G5p, DL160 G5p Special Server, DL160 G6, DL160 G6 Special Server, DL160se G6, DL165 G5p, DL165 G5p Base, DL165 G5p Efficiency, DL165 G5p Entry, DL165 G5p Performance, DL165 G6, DL165 G7, DL165 G7 Performance, DL165 G7 Special Server, DL170h G6, DL180 G6, DL180 G6 Special Server, DL2x170h G6, DL320 G6, DL320 G6 Entry, DL320 G6 High Efficiency, DL320 G6 Performance, DL360 G6, DL360 G6 Base, DL360 G6 Efficiency, DL360 G6 Entry, DL360 G6 Performance, DL360 G7, DL360 G7 Base, DL360 G7 Entry, DL360 G7 Performance, DL360 G7 Special Server, DL370 G6, DL370 G6 Base, DL370 G6 Performance, DL380 G5 High Availability Storage Server, DL380 G5 Storage Server 2.7TB SAS Model, DL380 G5 Storage Server 6TB SATA Model, DL380 G6, DL380 G6 Base, DL380 G6 Entry, DL380 G6 High Efficiency, DL380 G6 Performance, DL380 G7, DL380 G7 Base, DL380 G7 Efficiency, DL380 G7 Entry, DL380 G7 Performance, DL385 G5p, DL385 G5p Base, DL385 G5p Entry, DL385 G5p High Performance, DL385 G6, DL385 G6 Base, DL385 G6 Entry, DL385 G6 High Performance, DL385 G7, DL385 G7 Base, DL385 G7 Entry, DL385 G7 Performance, DL4x170h G6, DL580 G7, DL580 G7 Base, DL580 G7 High Performance, DL585 G5 High Performance, DL585 G6, DL585 G6 Base, DL585 G6 Performance, DL585 G7, DL585 G7 Base, DL585 G7 Performance, DL785 G6, DL785 G6 Base, DL785 G6 Performance, ML330 G6, ML330 G6 Base, ML330 G6 Entry, ML350 G6, ML350 G6 Base, ML350 G6 Entry, ML350 G6 Performance, ML350 G6 Special Server, ML370 G6, ML370 G6 Base, ML370 G6 Entry, SL160s G6, SL160z G6, SL170z G6, SL2x170z G6
HPE StorageWorks Network Storage Gateway X3400, X3800, X9300
HPE StorageWorks Network Storage System X1400 2TB SATA Model, X1400 4TB SATA Model, X1600, X1600 12TB SATA Model, X1600 292GB SAS Model, X1600 5.4TB SAS Model, X1600 6TB SATA Model, X1600 7.5TB SAS Model, X1800, X1800 2.4TB SAS Model, X1800 292GB SAS Model, X1800 3.6TB SAS Model, X1800 6TB SATA Model |
|
